Description:

This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.

Physical Characteristics
Type	3x UPS Replacement
Voltage	6V
Amps	12A
Terminal Type	F2
Tab Size	0.25 inch
Container Material	ABS(UL-94HB)
Length	6 inches [151mm]
Width	2 inches [50.5mm]
Height	3.7 inches [94mm]
Operating Temperature	25±3? (77±5? )
Compatible Terminal Adapter
BT-ADT2T1	Battery terminal adapter F2 female (0.25”) to F1 male (0.1875”)
Performance
Internal Resistance	Approx.15m?
Max. Discharge Current	180A(5S)
Rated Capacity	12.00AH (20hr, 1.75V/cell,25?/77?) 11.31AH (10hr, 1.75V/cell,25?/77?) 10.15AH (5hr, 1.75V/cell,25?/77?) 9.23AH (3hr, 1.75V/cell,25?/77?) 6.92AH (1hr, 1.75V/cell,25?/77?)
Cycle Use	Charge Current Less Than 0.25CA 7.05V~7.35V@25?(77?)Temp. Coefficient -30mV/?
Floating Use	No limit on Initial Charging Current Voltage 6.75V~6.9V@25?(77?)Temp. Coefficient -20mV/?
Capacity affected by Temperature	40°C 103% 25°C 100% 0°C 86% -15°C 65%
Self-discharge	3 month Remaining capacity: 91% 6 month Remaining capacity:82% 12 month Remaining capacity:65%
Packaging Information
Product Weight	4.1 lbs [1.9kg]
Warranty Information
Warranty	6 Months
Compatibility Information
Model Number	Tripp-Lite OMNI UPS OMNI 500 LAN Tripp-Lite Smart UPS 900
